1 DATALOGIC MEMOR
96
5
SYSTEM
OPERATING SYSTEM Windows CE 5.0 Professional
MICROPROCESSOR Marvell XScale™ PXA310 @ 624 MHz
SYSTEM RAM MEMORY 128 MB
SYSTEM FLASH MEMORY 256 MB
POWER SUPPLY*
DC Supply 5 V ± 5%
Battery Pack
1 cell Li-Pol or Li-Ion 1100 mAh@3.7 V (nominal)
Alternatively 1 cell Li-Pol or Li-Ion 2000
mAh@3.7 V (nominal)
Internal Backup Battery Rechargeable Ni-MH 30 mAh (2 x 15 mAh cells)
COMMUNICATIONS
INTERFACES
Bluetooth Interface
COM5
Serial Interface
RS232
USB 1.1
COM1
COM6
LOCAL AREA NETWORK (LAN)
Summit IEEE 802.11abg
Frequency range: Country dependent, typically
2.4 and 5.2 GHz
CCX v4 Security
PERSONAL AREA NETWORK
(PAN)
Bluetooth® IEEE 802.15, Class 2, Version 2.0
* Use only DL approved battery packs power adapters.
