Datalogic Memor User Manual

TECHNICAL FEATURES
97
5
READING OPTIONS
LASER CHARACTERISTICS
SCANNING RATE -
BIDIRECTIONAL
104 ± 12 scan/sec
OPTICAL RESOLUTION 0.10 mm / 4 mils
SKEW ANGLE ± 50°
PITCH ANGLE ± 65°
LASER READER VLD, wavelength 630~680 nm
BAR CODES
UPC A, UPC E, EAN 8, EAN 13, Code 39, Code
39 Full ASCII, Code 32, Interleaved 2 of 5,
Industrial 2 of 5, Matrix 2 of 5, Code 128, EAN
128, Codabar, MSI, Plessey, Code 93, Code 11,
GS1 Databar
LASER CLASSIFICATION
Laser: Class 2
Safety class EN 60825-1:2001
LED CLASSIFICATION Led (Green Spot): Class 1
IMAGER CHARACTERISTICS
SCANNING RATE 60 frames/sec
OPTICAL RESOLUTION 0.13 mm / 5 mils
AIMING LASER VLD, wavelength 645~665 nm
BAR CODES
Decoded barcodes 1D:
UPC A, UPC E, EAN 8, EAN 13, Interleaved 2 of
5, Code 39, Code 39 Full ASCII, Codabar, Code
128, EAN 128, Code 93,
GS1 Databar, MSI,
Bookland EAN, ISSN EAN; Matrix 2 of 5, Standard
2 of 5
Decoded barcodes 2D:
PDF417, Da
taMatrix, QR, MicroPDF, RSS,
Maxicode, Aztec
Postal codes:
POSTNET, PLANET, Japan Post, Australia Post,
KIX Code, Royal Mail Code (RM4SCC), Intelligent
mail, UPU FICS

Datalogic Memor Specifications

General

Scan speed	104 sec/page
Wavelength	630 nm
Sensor type	Laser
Decoding standards	UPC A, UPC E, EAN 8, EAN 13, Code 39, Code 39 Full ASCII, Code 32, Interleaved 2 of 5, Industrial 2 of 5, Matrix 2 of 5, Code 128, EAN 128, Codabar, MSI, Plessey, Code 93, Code 11, GS1 Databar.
Product color	Black
Internal memory	256 MB
Built-in processor	PXA310
Display resolution	240 x 320 pixels
Processor frequency	624 MHz
Bluetooth	Yes
Standard interfaces	USB, RS-232
Battery type	Li-polymer/Li-ion
Input voltage	5 V
Power consumption	1100 mA
Safety	Class 2
Display	Reflective TFT 64K
Dimensions (WxDxH)	152 x 55 x 40 mm
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 50 °C

Weight and Dimensions

Weight	230 g
