Enter/Exit Programming Mode
248
PowerScan™ PD9530/PBT9500/PM9500
Enable/disable buttons
This feature offers the ability to enable or disable each key independently.
Figure 6. PowerScan 9500 Keypad
Key Programming
.
Enable a combination of the 4 keys
To configure this feature, scan the ENTER/EXIT PRO-
GRAMMING MODE bar code above, then the bar code
at
left followed by 4 digits from the Alphanumeric
characters in
Appendix D, Keypad
.
The last 3 digits must always be 0; the 4 bits of the
firs
t digit must be 1 if the corresponding key is
enabled; the four bits represent, starting from the
highest: Arrow Up, F2, F1, Arrow Down. End by scan-
ning the ENTER/EXIT bar code again.
Make a mistake? Scan the CANCEL bar code to
abort
and not save the entry string. You can then start
again at the beginning.
