Label ID
Product Reference Guide
107
Label ID — continued
Table 18
STEP ACTION EXAMPLES
1. Scan the ENTER/EXIT bar code (Scanner enters Programming Mode)
2.
Determine placement of the
L
abel ID characters BEFORE
or AFTER with regard to
scanned data using
Label ID
Control on page 108
Enable as Prefix Enable as Suffix Enable as Prefix Enable as Suffix
3.
Scan the bar code selecting the
symbology type you wish to
designate label ID characters
for using
Label ID
Symbology
Selection, starting on page
109
.
GS1 DataBar
Omnidirectional
Code 39
Interleaved 2 of
5
Code 32
4.
Custom Label ID example
(desired characters):
D B * = C 3 + P H
5.
Find hex equivalents from the
ASCII t
able (inside back cover),
then scan in these digits/
characters using the bar codes
in the section:
Keypad, starting on page
359
. f you make a mistake
before the last character, scan
the CANCEL bar code to abort
and not save the entry string.
You can then start again at the
beginning.
44 42 2A 3D 43 33 2B 50 48
6. Scan theENTER/EXI
T bar code (Scanner exits Label ID entry)
7.
Scan the ENTER/EXIT bar code
once again
(Scanner exits Programming Mode)
Result:
DB*[bar code
data]
[bar code
data]=C3
+[bar code data] [bar code data]PH
