Symbologies Enter/Exit Programming Mode

Product Reference Guide

237

Code 5 Check Character Transmission

This feature enables/disables transmission of an optional Code 5 check charac-

ter.

Code 5 Hex to Decimal Conversion

This feature enables/disables the conversion of hexadecimal label data to dec-

imal label data.

$CC5CT00

Code 5 Check Character Transmission = Don’t Send

$CC5CT01

Code 5 Check Character Transmission = Send

DEFAULT

$CC5HD00

Code 5 Hex to Decimal Conversion = Disable

$CC5HD01

Code 5 Hex to Decimal Conversion = Enable

DEFAULT

Default Chapter3
