Datalogic QuickScan I QM21X1 User Manual

Enter/Exit Programming Mode Code 4 and Code 5 Common Configuration Items
238 QuickScan™ I QM21X1 / QBT21X1
Code 4 and Code 5 Common Configuration Items
The following options apply to both Code 4 and Code 5 symbologies.
Code 4 and 5 Decoding Level
Decoding Levels are used to configure a bar code symbology decoder to be very
aggressive to very conservative, depending on customer needs. See "Decoding
Levels" on page 303 for more detailed programming instructions.
NOTE
This configuration item applies to Code 4 and Code 5.
$CC5DL00
Code 4 and Code 5 Decoding Level = Disable
$CC5DL01
Code 4 and Code 5 Decoding Level = 1
$CC5DL02
Code 4 and Code 5 Decoding Level = 2
$CC5DL03
Code 4 and Code 5 Decoding Level = 3
$CC5DL04
Code 4 and Code 5 Decoding Level = 4
$CC5DL05
Code 4 and Code 5 Decoding Level = 5
DEFAULT

Datalogic QuickScan I QM21X1 Specifications

General

Brand	Datalogic
Model	QuickScan I QM21X1
Category	Barcode Reader
Language	English
