INSTALLATION
23
2
2.5.4
SC6000 to Fieldbus Network Layout
The
SC6000
can
be
connec
ted
to
a
Fieldbus
network
(Ethernet,
DeviceNet,
or
Profi
bus)
to
communicate
with
a
remote
host
(for
example,
remote
PC
connected
via
Internet).
Connections
are
made
directly
through
cables
to
the
Fieldbus
connector
and
do
not
require
any converter or adapter.
Figure
31
–
Fieldbus Network
Figure
32
–
Dual Ethernet Connection
CAB-SC6003
Extended I/O
SC6000
Power/Net
CAB-SC6013
NULL-MODEM
Cable
FIELDBUS
VAC INPUT
PWO
AUX
Host PLC
SC6000
NULL-MODEM
Cable
ETHERNET
VAC INPUT
PWO
AUX
HUB
Host 1
ETHERNET
HU
B
Host 2
CAB-SC6003
Extended I/O
Power/Net
CAB-SC6013
32
