6 TECHNICAL FEATURES
ELECTRICAL FEATURES
Supply Voltage
10 to 30 Vdc
Power Consumption
6.5 W typical
800 mA to 300 mA max. (including startup current)
Communication Interfaces
Main (isolated)
Modem
RS232
RS232
RS485 full-duplex
Auxiliary
RS232
Other
Lonworks
Ethernet
1.25 Mb/s
100 Mb/s
ModelDependent Communication
Interfaces
Ethernet (dual)
DeviceNet
Profibus
100 Mb/s
up to 500 Kb/s
up to 12 Mb/s
Inputs (optocoupled NPN or PNP)
Encoder, PS, PS Aux, 3 polarity insensitive
optocoupled inputs
Outputs (optocoupled)
6 optocoupled outputs, 3 relay control outputs
USER INTERFACE
LCD Display
4 lines by 20 characters LCD
Keypad
6 keys
LED Indicators
Power ON
TX data
RX data
Ethernet
PS
PS Aux
TACH
Networks
Controller
Scanners
SOFTWARE FEATURES
Configuration Modes
Genius™ utility program
Parameter Storage
Non-volatile extractable FLASH card
ENVIRONMENTAL FEATURES
Operating Temperature
0° to +50 °C (+32° to +122 °F)
Storage Temperature
-20° to +70 °C (-4° to +158 °F)
Humidity
90% non condensing
Vibration Resistance
EN 60068-2-6
14 mm @ 2 to 10 Hz; 1.5 mm @ 13 to 55 Hz;
2 g @ 70-200 Hz; 2 hours on each axis
Shock Resistance
EN 60068-2-27
30 g; 11 ms;
3 shocks on each axis
Protection Class EN 60529
IP64*
PHYSICAL FEATURES
Mechanical Dimensions
320 x 250 x 90 mm (12.6 x 9.84 x 3.54 in)
Weight
3.3 kg. (7.26 lb)
* sealed connectors required, including the Harting RJ Industrial® Push Pull Ethernet
connector.
