Datalogic SC6000 User Manual

SC6000
24
2
2.6 KEYPAD AND DISPLAY
The SC6000 display shows different messages according to the following operating modes.
Use the SC6000 keypad to scroll through the windows or navigate in the menu.
2.6.1 Standard Mode
Upon startup, the Diagnostic Mask window is visualized by default. Using the UP and DOWN
arrow keys it is possible to scroll through the following windows:
1) Diagnostic Mask Window
2) Reading Performance Window
3) Reading Mask Window
4) I/O Status Window
5) Conveyor Speed
6) System Info Window
7) Last Code & Read Mask
8) Alarms
Diagnostic Mask Window (Default Window)
This window illustrates the status of each node (of each scanner of the cluster).
S
c
a
n
*
*
*
*
*
*
*
*
S
t
a
t
e
A
B
C
D
E
F
G
H
The slave scanners are listed as letters (A, B, C, etc.) [or numbers (01, 02, 03, etc.)
depending on the System Information Section>User Interface Style configuration parameter
in Genius].
Above each scanner position a symbol indicates the scanner status according to the
following convention:
–
From the startup the node NID has not been discovered.
?
At the startup of the system the NID has been discovered but the node does not answer to the
master.
*
The node status is OK.
!
The node returns an error code to the diagnostic Laser Off.
&
The node returns an error code to the diagnostic Motor Off.
%
The node is in monitor mode.
Other messages can also be displayed:
“Empty scan cluster“
No scanner has been discovered within the cluster.
“No slave expected“
A scanner not expected by the system configuration has been discovered.
“Energy Saving”
The Energy Saving feature has been activated.
(see Genius™ program Help On-Line)
