The Auto PackTrack procedure when run from the SC6000 keypad, requires a system
reset before the calibration is recognized. See the Auto PackTrack Setup procedure in
par. 2.7.3. The Auto PackTrack setup may be performed in Genius™. For more details see
the Help On-Line.
2.7 AUTO PACKTRACK™ CALIBRATION FOR READING STATION
USING SC6000 MENU
2.7.1 Auto PackTrack Conditions and Limits
The Conditions and Limits for Auto PackTrack Calibration are summarized here for
convenience and are also integrated into the following procedure descriptions:
The following scanners are supported by Auto PackTrack Calibration: DS6400 (*see note
below), DX6400 (*see note below), DS8100A, DX8200A
Before performing the Auto PackTrack Calibration procedure, if a system reset or power
reset is performed, wait for all the scanners to be available (up to 60 sec.) before
proceeding.
Operating Mode must be either PackTrack or Continuous
If the system Presence Sensor and Encoder are used, the correct Encoder Step value
must be set and the Presence Sensor must be connected to the SC6000 PS input.
If instead the PPA-8000 Photocell Array is used, it must be connected to the SC6000 PS
and PSAUX inputs, and the Encoder, if present, must be physically disconnected.
DX scanners which are calibrated automatically cannot be automatically replaced by DX
scanners with a previous sw version (earlier than 6.80). You must either update the old
scanner software prior to substitution, or complete the calibration manually, after
installation, by setting the PSOffset and Direction parameters.
