Extended System-Level Command Functions
80 Class Series Programmer’s Manual
(RI) RFID Configuration – This command configures the optional RFID interface module, as follows:
Table 5-8: RFID Configuration Set Commands
Value Units / Interpretation RFID Configuration Definition / Function
D = Disable Disables the RFID module. (“N” is also a valid disabler.)
H = HF Enables the RFID module for HF (Securakey).
U = UHF Enables the RFID module for UHF Class 1 (Alien).
Mn
where n:
M = UHF Enables the RFID module for UHF Multi-Protocol (Samsys).
AIhh
where hh: 2-Chararacter Hex ID Sets the Application Family Identifier (AFI), (HF only)
ALn
and where n:
E = Enable,
D = Disable
Allows locking the AFI after writing (HF only)
DIhh
where hh: 2-Chararacter Hex ID Sets the Data Storage Format Identifier (DSFID), (HF only)
DLn
and where n:
E = Enable,
D = Disable
Allows locking the DSFID after writing (HF only)
Shh
where hh: 2-Chararacter Hex ID Sets the Electronic Article Surveillance (EAS) set, representing the manufacturer’s code. (HF only)
Lhh
where hh: 2-Chararacter Hex ID Sets the Lock Code (Alien UHF only)
Rn
where n: 0 – 9 Sets the number of retries for RFID functions
Wn
where n:
E = Enable,
D = Disable
Allows locking the tag after writing.
En
where n:
E = Enable,
D = Disable
Allows erasures of the tag on error (HF only)
Pxxx
where xxx: 3-digit value
Sets the tag encoding position: A value of 0.00 causes the print position to be used; or, a value
greater than 0 causes the presented position to be used. (Subject to change.)
