Maintenance and Adjustments
2-1
2.0 Introduction
This section covers maintenance and alignment procedures.
2.1 Maintenance
Recommended items, techniques, and schedules to keep the printer in top working order are detailed
below. The following items will help you safely and effectively maintain the printer:
• Isopropyl alcohol
• Cotton swabs
• Clean, lint-free cloth
• Soft-bristle brush
• Soapy water/mild detergent
• Compressed air
• Printhead Cleaning Cards or Printhead Cleaning Film
CAUTION
f For your safety and to avoid damaging the unit, always turn OFF the power switch
and unplug the AC power cord before servicing the printer.
f Isopropyl alcohol is a flammable liquid -- take proper precautions when using this
solvent.
Recommended Maintenance Schedule
Component / Area Cleaning Interval Method / Supplies
Printhead
After every roll of
media.
A cotton swab dampened with isopropyl alcohol
then wiped across the surface and, if necessary,
Printhead Cleaning Cards or Cleaning Film when
needed; see Section 2.1.1.
Platen
After every roll of
media.
A cotton swab or cloth dampened with isopropyl
alcohol wiped across the roller, rotating as needed
to clean the entire surface; see Section 2.1.2.
Peel-Off Roller
After every roll of
media.
Rotate the peel-off roller and clean it thoroughly
using isopropyl alcohol and a cotton swab.
Media Path / Media
Sensor / Peel Bar
As needed.
Compressed air or a soft brush to remove all
debris, and isopropyl alcohol to remove adhesive
buildup; see Section 2.1.3.
Interior As needed.
Compressed air or a soft brush to remove all
debris.
Exterior Surfaces As needed.
A cloth dampened with mild detergent wiped
across the surface until clean.
