Neptune 5000
© Copyright Datem Limited 2014
35
cap. Appropriate precautions should be taken to avoid all contact with the oil
in the lower section.
1. Remove the top cap as previously described,
2. Using appropriate lifting apparatus, turn the pod upside down, and stand it
on a suitable Topside,
3. Remove the M6 cap bolts from around the lower end-cap,
4. Fit two of the M6x35 cap bolts to the jacking holes, and systematically turn
them, jacking the entire end cap out of the vessel,
5. Fit a lifting eye into the central M12 tapped hole, and attach an appropriate
hoist,
6. Slowly hoist the end cap and transformer assembly,
7. Place the end cap and transformer assembly to one side to avoid risk of
lifting apparatus failure, taking care to rest the cap on its base, not on the
transformer.
8. The transformer can now be removed from the base cap.
Electrical Installation
A wiring schematic diagram of the Power Pod is illustrated in Drawing 1677-
03-SCH, which can be found on the following page.
