Neptune 5000
© Copyright Datem Limited 2014
9
document is intended to give technical staff a basic understanding of the
overall system, its assemblies, and relevant information to enable routine
maintenance and repair.
System Specification
Dimensions 2.1m * 2.1m * 2.6m
Weight in Air 4000kg approx
Weight in Sea Water 3500 kg approx
Maximum Operating Pressure 300Bar
Thrust Capacity 35kN
Maximum Penetration 20 Metres
Water Depth 3000 Metres
Power requirement 240Vac 1ph 50/60 Hz, 16A
Penetration Speed
/ Custom
Cone Type Non Subtraction Piezo Digital Cone
Frame Inclination Resolution 1.0°
Acquisition RS 232 19,200 baud
Cone Data Rate Selectable up to 20Hz
Frame Sensor Data Rate 1 Hz
Topside Software Windows 7, Vista & XP Compatible
General System Maintenance
When the system is in operation, it should be washed down with clean, salt-
free water whenever it is returned to the deck of the ship. This will reduce
corrosion, and reveal any damage to the frame, pods, compensator, thruster,
or cables.
The electrical cables connected to the sensors, pods, and auxiliary equipment
should be visually inspected regularly to ensure there are no chafes or cuts in
the insulation. The connectors on both ends of the cables should be tightly
fitted with no face gap, and the lock-rings should be finger-tight.
All fastenings should be regularly checked to ensure they are present, tight,
and there is no damage to them or the items they are fitted to.
Reference should be made to the following sections of the manual to fulfil
detailed maintenance requirements, relevant to each individual sub-system
during operation.
