Deif AGC-3 User Manual

4.1.13 Slot #4, combination outputs for GOV/AVR or transducer (option EF4)
Term. Function Description
65 +/-25 mA Configurable
66 0
67 Not used
68 Not used
69 NO Relay 69
70 Com.
71 NO Relay 71
72 Com.
4.1.14 Slot #4, PWM output for GOV and combination output for AVR (option
EF5)
Term. Function Description
65 +/-25 mA AVR set point output
66 0
67 PWM + PWM speed governor signal
68 PWM -
69 NO Relay output for AVR. Raise voltage
70 Com.
71 NO Relay output for AVR. Lower voltage
72 Com.
4.1.15 Slot #4, PWM output for GOV and combination output for AVR (option
EF6)
Term. Function Description
65 Not used
66 Not used
67 0 Speed governor, AVR or transducer output 68
68 +/-25 mA
69 PWM - PWM speed governor signal
70 PWM +
71 0 Speed governor, AVR or transducer output 72
72 +/-25 mA
AGC-3 installation instructions 4189340728
UK
Hardware
DEIF A/S Page 30 of 65
