4.1.26 Slot #8, engine interface communication (option H5)
Term. Function Description
126 Not used CAN bus-based engine interface communication
127 Not used
128 CAN-L
129 GND
130 CAN-H
131 CAN-L
132 GND
133 CAN-H
4.1.27 Slot #8, Cummins engine interface communication (option H6)
Term. Function Description
126 Not used Modbus RTU (RS-485)
127 DATA - (B)
128 Not used
129 DATA + (A)
130 Not used
131 DATA - (B)
132 GND
133 DATA + (A)
4.1.28 Slot #8, 7 digital inputs (option M13.8)
Term. Function Technical data Description
126 Com. Common Common for terminals 127-133
127 Digital input 127 Optocoupler Configurable
128 Digital input 128 Optocoupler Configurable
129 Digital input 129 Optocoupler Configurable
130 Digital input 130 Optocoupler Configurable
131 Digital input 131 Optocoupler Configurable
132 Digital input 132 Optocoupler Configurable
133 Digital input 133 Optocoupler Configurable
AGC-3 installation instructions 4189340728
UK
Hardware
DEIF A/S Page 37 of 65
