4.1.21 Slot #6, 4 relay outputs (option M14.6)
Term. Function Technical data Description
90 NE/ND Relay 90
250 V AC 5 A
Configurable
91 Com.
92 NE/ND Relay 92
250 V AC 5 A
Configurable
93 Com.
94 NE/ND Relay 94
250 V AC 5 A
Configurable
95 Com.
96 NE/ND Relay 96
250 V AC 5 A
Configurable
97 Com.
4.1.22 Slot #6, 4 analogue inputs (option M15.6)
Term. Function Technical data Description
90 Analogue input 91 - Common Configurable
91 Analogue input 91 + 4 to 20 mA in
92 Analogue input 93 - Common Configurable
93 Analogue input 93 + 4 to 20 mA in
94 Analogue input 95 - Common Configurable
95 Analogue input 95 + 4 to 20 mA in
96 Analogue input 97 - Common Configurable
97 Analogue input 97 + 4 to 20 mA in
4.1.23 Slot #6, analogue outputs for GOV/AVR or transducer (option F1)
Term. Function Description
90 Not used
91 0 Transducer output
92 0(4) to 20 mA
93 Not used
94 Not used
95 0 Transducer output
96 0(4) to 20 mA
97 Not used
AGC-3 installation instructions 4189340728
