4.1.19 Slot #5, AC measuring - AGC BTB unit
The I/O list below is for the AGC BTB unit.
Term. Function Technical data Description
73 I L1, s1 Bus A current L1 x/1 A or x/5 A input
74 I L1, s2
75 I L2, s1 Bus A current L2 x/1 A or x/5 A input
76 I L2, s2
77 I L3, s1 Bus A current L3 x/1 A or x/5 A input
78 I L3, s2
79 U L1 Bus A voltage L1 Max. 690 V AC phase-phase value
80 Not used
81 U L2 Bus A voltage L2 Max. 690 V AC phase-phase value
82 Not used
83 U L3 Bus A voltage L3 Max. 690 V AC phase-phase value
84 U
NEUTRAL
Bus A voltage neutral
85 U L1 Bus B voltage L1 Max. 690 V AC phase-phase value
86 Not used
87 U L2 Bus B voltage L2 Max. 690 V AC phase-phase value
88 U
NEUTRAL
Bus B voltage neutral
89 U L3 Bus B voltage L3 Max. 690 V AC phase-phase value
4.1.20 Slot #6, 7 digital inputs (option M13.6)
Term. Function Technical data Description
90 Com. Common Common for terminals 90-97
91 Binary input 91 Optocoupler Configurable
92 Binary input 92 Optocoupler Configurable
93 Binary input 93 Optocoupler Configurable
94 Binary input 94 Optocoupler Configurable
95 Binary input 95 Optocoupler Configurable
96 Binary input 96 Optocoupler Configurable
97 Binary input 97 Optocoupler Configurable
AGC-3 installation instructions 4189340728
UK
Hardware
DEIF A/S Page 33 of 65
