● Current/voltage unbalance (60)
● Loss of excitation/overexcitation (40/32RV)
● Non-essential load/load shedding, 3 levels (I, Hz, P>, P>>)
● Multi-inputs (digital, 4 to 20 mA, 0 to 40 V DC, Pt100, Pt1000 or RMI)
● Digital inputs
2.2.4 Busbar protection (ANSI)
● 3 × over-voltage (59)
● 4 × under-voltage (27)
● 3 × over-frequency (81)
● 4 × under-frequency (81)
● Voltage unbalance (60)
2.2.5 Display
● Prepared for remote mounting
● Push-buttons for start and stop
● Push-buttons for breaker operations
● Status texts
2.2.6 M-Logic
● Simple logic configuration tool
● Selectable input events
● Selectable output commands
2.3 Standard and optional applications
In the following sections, the standard and optional applications of the AGC will be presented. In addition, the
correct application configuration for the different applications is listed. It is only possible to use the unit for one
of the purposes, for example AMF (Automatic Mains Failure). The selection must be made on site.
All units are supplied with AMF as factory setting.
AGC-3 installation instructions 4189340728
UK
General product information
DEIF A/S Page 7 of 65
