7.4.2 Alarm Status
The Terminal provides an alarm message system which currently displays 12 different types of
alarm events. There are several alarm events assigned to each of the 4 relays. In case an
alarm event has occurred it is acknowledged on the display in standard working mode in the
third line by a flashing message “Alarm exists!”. This message is shown alternately with the
time and date line:
In order to specify the type of alarm event proceed as follows:
After identification as administrator you reach the functional menu by pressing the “F”-button.
Moving the arrow keys and confirming your choice by pressing the green button or directly
entering the prefixed number leads you to the submenu “4 Device Manager”.
1 Now select “2 Alarm Status” by
moving the arrow keys and confirm
again with the green button.
2 The screen on the left side shows the
four relais with their current status.
Relays No.3 shows an “x” mark which
means that there is an alarm event
present assigned to relays No.3. For
alarm details press the number of the
marked relays on the keypad (here:3).
3 The displays now shows detailed
information about the current alarm
event: In Cabinet 01 there has been a
main power failure.
You now have the possibility to clear this
alarm by pressing the “F”-button.
32 ps_terminalc4_em v250909
proxSafe Terminal C4
Alarm Summary
1:o 2:o 3:x 4:o
1 - 4: Alarm Details
C:Back F:Clear all
1 Device Test
2Alarm Status
3 Readdress Cabinets
Alarm 3 Cabinet 01
Event1/1:
Main Power Failure
F:Clear :View
deister electronic
Present Card/keyTag
Alarm Exists!
:History 0-9:PIN
deister electronic
Present Card/keyTag
Tu 06.05.06 8.45.11
:History 0-9:PIN
