Control Section 6
DIAGNOSTICS
Diagnostics
Back
Relay Status Temperature Probes
Data History Relay Outputs
!
Configuration Screen\Diagnostics
• From the Diagnostics Screen the following screens are
accessible:
• Relay Status
• Data History
• Temperature Probes
• Relay Outputs
• Select the title frame to navigate there.
RELAY STATUS
• This screen is a list of relay’s with their status to the right.
• The status displays either on or off.
Relay Status
Heater: On/Off
Heater Fan: On/Off
Interior Light: On/Off
Back
Heated
!
Configuration Screen\Diagnostics\Relay Status
Heated Unit
Relay Status
Compressor
: On/Off
Condenser Fan: On/Off
Evaporator Fan: On/Off
Frame Heater: On/Off
Defrost Heater: On/Off
Interior Light: On/Off
Back
Freezer
!
Configuration Screen\Diagnostics\Relay Status
Freezer
Relay Status
Compressor 1: On/Off
Condenser Fan: On/Off
Evaporator Fan: On/Off
Frame Heater: On/Off
Defrost Heater: On/Off
Interior Light: On/Off
Compressor 2: On/Off
Back
Split System
!
Configuration Screen\Diagnostics\Relay Status
1 Section Dual Temperature Unit
