Part Number GA_SM 08/18 43
Section 6 Control
IP ADDRESS SETUP SCREEN
IP Address Setup:
Back
IP Address:
Default Gateway:
Netmask:
192 2
2168
255 255 0255
192 2 1168
Obtain an IP address automatically
Use the following IP address:
!
Configuration Screen\Network Connection\Cog Icon
• Selecting back navigates to the previously viewed
screen and activates any values that were changed.
• Select Obtain an IP address automatically or select Use
the following IP address. The feature that is active will
have a circle that looks full.
• If Obtain an IP automatically is selected the majority of
the screen will be inactive. The IP address will change
every time the unit is powered up.
• If Use the following IP address is selected continue to fill
in the screen, IP address, Netmask and Default Gateway.
• Touching any of the boxes will bring up a
numeric keypad.
• Each white box can contain up to three digits, a
number between 0 and 255.
PASSWORD
Back
Enter Password
Confirm Password
Password can be up to up to six
alphanumeric characters long
!
Settings Screen\Password
• Access to this page requires the manager password.
• Selecting the Enter Password icon will open the
keyboard. Enter new password; it can be up to six letters
and numbers.
• Select the Confirm Password icon will open the
keyboard. Confirm the new password.
• If the passwords do not match they will need to be
reentered.
Back
Enter Password
Confirm Password
Password can be up to up to six
alphanumeric characters long
Passwords do not match
Please re-enter
!
