44 Part Number GA_SM 08/18
Control Section 6
FIRMWARE UPDATE
Update Firmware
Back
START
1. Insert USB memory device into USB port
located behind louvered access panel on
end shroud or at back of upper machine
compartment.
2. Touch start button to begin download.
3. Do not remove device until prompted.
3. Touch “Back” to return to “Home Screen”.
!
Settings Screen\Firmware Update
With Manager Password
• Access to this page requires the manager password.
1. Insert USB memory device into USB port located on
bottom of the front shroud to the left of the control
display. Skip this if updating via wireless.
2. Touch start button to begin download.
Updating Firmware
Updating
Do not remove memory
device or disconnect power
from unit
!
Firmware Updating In Process Screen
3. Do not remove device until prompted.
Update Firmware
Back
Firmware Update
Complete
Remove USB memory device
if used
!
Firmware Update Complete Screen
4. Remove USB device memory device if used.
Check Firmware Version with Firmware Update Screen
From the Settings Screen, select Firmware Update.
Instead of using the manager password, use the service
password, 9014766419.
Settings Screen\Firmware Update
With Service Password
To Next Page
