Removing the base cover
NOTE: Before working inside your computer, read the safety information that shipped with your computer and follow
the steps in Before working inside your computer. After working inside your computer, follow the instructions in After
working inside your computer. For more safety best practices, see the Regulatory Compliance home page at www.dell.com/
regulatory_compliance.
Procedure
1. Loosen the four captive screws on the base cover.
2. Remove the six screws (M2.5x9) that secure the base cover to the palm-rest assembly.
3. Remove the two screws (M2.5x9) from the back that secure the base cover to the palm-rest assembly.
4. Rotate the base cover from front to back and remove the base cover off the palm-rest assembly.
6
Removing the base cover 17
