Replacing the solid-state drive/Intel Optane
Enable the Intel Optane device after you replace it. For more information about enabling the Intel Optane device, see Enabling
Intel Optane memory.
NOTE: Before working inside your computer, read the safety information that shipped with your computer and follow
the steps in Before working inside your computer. After working inside your computer, follow the instructions in After
working inside your computer. For more safety best practices, see the Regulatory Compliance home page at www.dell.com/
regulatory_compliance.
CAUTION: Solid-state drives are fragile. Exercise care when handling the solid-state drive.
Procedure to replace M.2 2230 card
NOTE: This procedure applies only to systems shipped with a M.2 2230 card installed.
NOTE: Depending on the configuration ordered the system may have up to two M.2 cards installed. Supported card
configurations per M.2 card slot:
● M.2 2230 solid-state drive + 2230 card bracket
● M.2 2280 solid-state drive
● M.2 2280 Intel Optane
NOTE: For solid-state drives above 512 GB or Intel Optane above 118 GB a thermal shield is required for optimal heat
dissipation and is installed in the computer when these configurations are ordered. If these configurations are installed After
Point-of-Sale (APOS), contact Dell support for the thermal shield.
NOTE: Depending on the number of M.2 cards installed at Point-of-Sale, the thermal shield installed in the computer may
be a full shield or a half shield. If two M.2 cards are installed After Point-of-Sale (APOS) contact Dell support for the full
thermal shield.
1. Place the M.2 2230 card on the M.2 2230 card bracket.
2. Replace the screw (M1.6x2) that secures the M.2 2230 card to the M.2 2230 card bracket.
3. Align the notch on the M.2 2230 card with the tab on the M.2 card slot on the system board.
4. Slide the M.2 2230 card along with the bracket into the M.2 card slot on the system board.
5. Replace the screw (M2x3) that secures the M.2 2230 bracket to the palm-rest assembly.
19
Replacing the solid-state drive/Intel Optane 43
