Replacing the battery (full-length)
NOTE: Before working inside your computer, read the safety information that shipped with your computer and follow
the steps in Before working inside your computer. After working inside your computer, follow the instructions in After
working inside your computer. For more safety best practices, see the Regulatory Compliance home page at www.dell.com/
regulatory_compliance.
Procedure
1. Align the screw holes on the battery with the screw holes on the palm-rest assembly.
2. Replace the six screws (M2x5) that secure the battery to the palm-rest assembly.
3. Connect the battery cable to the system board.
Post-requisites
Replace the base cover.
11
26 Replacing the battery (full-length)
