Removing the display panel
NOTE: Before working inside your computer, read the safety information that shipped with your computer and follow
the steps in Before working inside your computer. After working inside your computer, follow the instructions in After
working inside your computer. For more safety best practices, see the Regulatory Compliance home page at www.dell.com/
regulatory_compliance.
Prerequisites
1. Remove the base cover.
2. Remove the wireless card.
3. Remove the display assembly.
4. Remove the display bezel.
Procedure
NOTE: Ensure that the display assembly is placed on a clean and flat surface.
1. Remove the four screws (M2x3) that secure the display panel to the display back-cover and antenna assembly.
2. Gently lift the display panel and turn it over.
40
Removing the display panel 79
