Removing the display bezel
NOTE: Before working inside your computer, read the safety information that shipped with your computer and follow
the steps in Before working inside your computer. After working inside your computer, follow the instructions in After
working inside your computer. For more safety best practices, see the Regulatory Compliance home page at www.dell.com/
regulatory_compliance.
Prerequisites
1. Remove the base cover.
2. Remove the wireless card.
3. Remove the display assembly.
Procedure
NOTE: Ensure that the display assembly is placed on a clean and flat surface.
1. Using a plastic scribe, unhook and release the sides of the display bezel from the display assembly as shown in the image in
the following order: Top (camera)->Left->Right->Bottom (Alienware logo).
NOTE: Note the location of each adhesive tape securing the display bezel to the display assembly (as shown in yellow).
2. Lift the display bezel off the display assembly.
34
72 Removing the display bezel
