Installing the Coin-Cell Battery
1 Place the coin-cell battery into the slot on the system board.
2 Press the coin-cell battery downward until the release latch springs back into place and secures it.
3 Install:
a PCIe card
b left cover
4 Follow the procedures in After Working Inside Your Computer.
Removing the Heatsink
1 Follow the procedures in Before Working Inside Your Computer.
2 Remove:
a left cover
b memory shroud (center)
3 Disconnect the heatsink fan cable from the system board.
4 Remove the captive screws that secure the heatsink.
22
Removing and installing components
