3. Replace the twelve silver M2 x 5-mm screws on the palm rest in the holes labeled "P".
4. Gently connect the ExpressCard and touch pad cables to the system board using the latches near the cable connectors.
5. Replace the coin-cell battery (see Replacing the Coin-Cell Battery).
6. Replace the display assembly (see Replacing the Display Assembly).
7. Replace the module with Bluetooth wireless technology (see Replacing the Card With Bluetooth Wireless Technology).
8. Replace the keyboard (see Replacing the Keyboard).
9. Replace the LED cover (see Replacing the LED Cover).
10. Turn the computer upside down.
11. Replace the two silver M2 x 5-mm screws in the base of the computer.
12. Gently connect the fingerprint reader/wireless switch cable to the system board using the connector release.
13. Replace the solid state drive (see Replacing the Solid State Drive and Cable Assembly).
14. Replace the memory module (see Replacing the Memory Module).
15. Replace the WLAN and WWAN cards (see Replacing the WLAN/WiMax Card and Replacing a WWAN Card).
16. Replace the service panel (see Replacing the Service Panel).
17. Follow the instructions in After Working on Your Computer.
