Dell Latitude E4200 - Removing the System Board Assembly

Back to Contents Page
 System Board Assembly
Dell™Latitude™E4200ServiceManual
Removing the System Board Assembly
Replacing the System Board Assembly
The system board's BIOS chip contains the Service Tag, which is also visible on a barcode label on the bottom of the computer. The replacement kit for the
system board includes media that provides a utility for transferring the Service Tag to the replacement system board.
The system board assembly is made up of three separate boards:
l Right I/O board
l  System board
l Left I/O board
All three boards must be replaced when replacing the system board assembly.
Removing the System Board Assembly


1. Follow the instructions in Before Working on Your Computer.

2. Remove the service panel (see Removing the Service Panel).

3. Remove the WLAN and WWAN cards (see Removing the WLAN/WiMax Card and Removing a WWAN Card).

4. Remove the memory module (see Removing the Memory Module).

5. Remove the solid state drive (see Removing the Solid State Drive and Cable Assembly).

6. Remove the LED cover (see Removing the LED Cover).

7. Remove the keyboard (see Removing the Keyboard).

8. Remove the module with Bluetooth
®
wireless technology (see Removing the Card With Bluetooth Wireless Technology).

9. Remove the display assembly (see Removing the Display Assembly).

10. Remove the coin-cell battery (see Removing the Coin-Cell Battery).

11. Remove the palm rest assembly (see Removing the Palm Rest Assembly).

12. Remove the DC power cable (see Removing the DC Power Cable).

13. Disconnect the cable to the right I/O board by gently pulling on the connector release.

14. Remove the two M2 x 3-mm screws from the right I/O board.

15. Lift the left side of the right I/O board, and pull the board away from the base assembly at an angle.
NOTE: System boards sold to certain government agencies in the United States must comply with the regulations set forth in the Trade Agreements Act
of 1979 (TAA).
NOTE: System boards that comply with the Trade Agreements Act (TAA) of 1979, ship with a BIOS chip on a socketed daughter card that is pre-installed
on the system board. Do not uninstall the daughter card.
CAUTION: Before working inside your computer, read the safety information that shipped with your computer. For additional safety best
practices information, see the Regulatory Compliance Homepage on www.dell.com at: www.dell.com/regulatory_compliance.
