1. Slide the card into the connector labeled WWAN.

2. Press the card down and hold it in place.

3. Replace the M2 x 3-mm screw.

4. Connect the white antenna cable to the connector labeled "main" (white triangle), and connect the black antenna cable to the connector labeled
"aux" (black triangle).

5. Replace the service panel (see Replacing the Service Panel).

6. Follow the procedures in After Working on Your Computer.
Back to Contents Page

NOTICE: The connectors are keyed to ensure correct insertion. If you feel resistance, check the connectors on the card and on the system board,
and realign the card.
NOTICE: To avoid damage to the WWAN card, ensure the cables are not under the card when you replace it.
NOTICE: Insert a WWAN card only into the slot labeled WWAN.
