Mini Tower Computer Parts 161
8 If you are installing the PCI Express card into the x16 card connector,
position the card so the securing slot is aligned with the securing tab.
1 card fully seated 2 card not fully seated
3 bracket caught outside of slot 4 bracket within slot
1
2
3
4
