42 Desktop Computer Views
Diagnostic lights four lights on the front panel (See
"Diagnostic Lights" on page 106.)
Standby power light AUX_PWR on the system board
Communications
Network adapter 10/100/1000 Ethernet LAN on system board
Expansion Bus
Bus type PCI 2.3
PCI Express 1.0A
SATA 1.0A and 2.0
USB 2.0
Bus speed PCI: 133 MB/s
PCI Express x16: 8 GB/s bidirectional speed
SATA: 1.5 Gbps and 3.0 Gbps
USB: 480 Mbps
Cards standard configuration supports low-profile
cards only;
with optional riser-card cage, computer
supports half-length, full-height cards. Full-
height cards are supported in the 6.875-inch
riser card cage.
PCI: without riser-card cage
connectors
two
card size
low profile
connector size
120 pins
connector data width
(maximum)
32 bits
PCI Express: without riser-card
cage
connectors
one x16
card size
low profile
power
25 W (maximum)
Controls and Lights
