Dell PowerEdge R750xa - Installing the IDSDM Module

Figure 131. Removing the IDSDM module
Next steps
1. Replace the IDSDM module.
Installing the IDSDM module
Prerequisites
1. Follow the safety guidelines listed in the Safety instructions.
2. Follow the procedure listed in Before working inside your system.
Steps
1. Locate the IDSDM connector on the system board.
NOTE:
For information on the exact location of IDSDM on system board, see System board jumpers and connector
section.
2. Align IDSDM module with the connector on the system board.
3. Press the IDSDM module until firmly seated on the system board.
