Figure 35. Removing a cooling fan
Next steps
1. Replace a cooling fan.
Installing a cooling fan
Prerequisites
1. Follow the safety guidelines listed in the Safety instructions.
2. Follow the procedure listed in Before working inside your system.
Steps
Align and slide the cooling fan into the cooling fan cage assembly until the fan clicks into place.
NOTE: The air flow arrow on the cooling fan must face towards rear side of the system.
42 Installing and removing system components
