Dell PowerEdge R930 - Memory Specifications; Drive Specifications

NOTE: To use slots 6 through 10, all four processors must be installed.
NOTE: Do not install a full-height expansion card on PCIe slot 2/10.
Memory specications
The PowerEdge R930 system supports DDR4 registered DIMMs (RDIMMs) and load-reduced DIMMs (LRDIMMs). Supported memory bus
frequencies are 1866 MT/s, 2133MT/s, or 2400 MT/s.
Table 16. Memory specications
Memory module sockets Memory capacity Minimum RAM Maximum RAM
Ninety-six 240-pin sockets
• 64 GB quad rank (LRDIMMs)
• 4 GB or 8GB single rank
(RDIMMs)
• 8 GB, 16 GB, or 32 GB dual
rank (RDIMMs)
• 192 GB with dual processor
with 4 memory risers
• 384 GB with quad processor
with 8 memory risers
• 3.07 TB with dual processor
with 4 memory risers
• 6.14 TB with quad processor
with 8 memory risers
NOTE:
• Each memory riser supports 12 memory module slots.
• Each processor supports two memory risers.
Drive specications
Hard drives
The PowerEdge R930 system supports SAS and SATA hard drives and Solid State Drives (SSDs).
Table 17. Supported hard drive and SSD options for the PowerEdge R930 system
Four hard drive systems Up to four 2.5 inch, internal, hot-swappable SAS hard drives in hard
drive slots 0 through 3.
This conguration supports:
• 6 Gbps and 12 Gbps I/O operations on SAS drives.
• 6 Gbps on SATA drives.
Twenty four hard drive systems (SAS/SATA) Up to twenty four 2.5 inch, internal, hot-swappable SAS/SATA hard
drives.
This conguration supports:
• 6 Gbps and 12 Gbps I/O operations on SAS drives.
• 6 Gbps on SATA drives.
NOTE: With a single Unied mode daughter card and
PERC 9 card the hard drives are located in hard drive slots
0 through 24 (bay 1).
NOTE: With two Performance mode daughter cards and
two PERC 9 cards the hard drives are located in hard drive
slots 0 through 11 (bay 1) and 0 through 11 (bay 2)
26 Technical specications
