Installing the memory riser and fan cage
Prerequisites
CAUTION: Many repairs may only be done by a certied service technician. You should only perform troubleshooting and simple
repairs as authorized in your product documentation, or as directed by the online or telephone service and support team.
Damage due to servicing that is not authorized by Dell is not covered by your warranty. Read and follow the safety instructions
that came with the product.
NOTE: Before installing the memory riser and fan cage, ensure there are no loose cables from the hard drive backplane. If the
cables are not latched, the cage will not seat rmly into the chassis.
1 Follow the safety guidelines listed in the Safety instructions section.
2 Follow the procedure listed in the Before working inside your system section.
Steps
1 Lift the memory riser and fan cage by holding the cage handle and back of the cage.
2 Align the guide rails on the memory riser and fan cage with the guides on the chassis.
3 Lower the memory riser and fan cage into the system until it is rmly seated on the system board.
4 Lower the cage handle until the cage handle locks into place.
