Dell PowerEdge R930 - Hard Drives

a Memory riser and fan cage
b Cooling fans
c Memory risers
d Memory riser blanks, if removed
2 Follow the procedure listed in the After working inside your system section.
Related links
Safety instructions
Before working inside your system
Removing a memory riser
Removing a cooling fan
Removing the memory riser and fan cage
Removing a memory riser blank
Installing the memory riser and fan cage
Installing a cooling fan
Installing a memory riser
Installing a memory riser blank
After working inside your system
Hard drives
Your system supports Entry Hard Drives and Enterprise Class Hard Drives. Entry Hard Drives are designed for 5x8 operating environment
with less workload rating to drives, and Enterprise Class Drives are designed for 24x7 operating environment. Selecting the correct drive
class enables the critical areas of quality, functionality, performance, and reliability to be optimized for the target implementation.
NOTE
: Do not mix Enterprise Class Drives with Entry Hard Drives.
Choosing the right drive type depends on the usage pattern. Improper use of Entry Hard Drives (workload rating exceed 55 TB/year) leads
to signicant risk and increase the drives failure rate.
For more information on these hard drives, see the 512e and 4Kn Disk Formats whitepaper and 4K Sector HDD FAQ document at
Dell.com/poweredgemanuals.
Depending on the conguration, your system supports one of the following:
Four hard drive
systems
Up to four 2.5-inch hot-swappable SAS hard drives, SATA hard drives, or SATA SSD
Twenty four hard
drive systems
Up to twenty four 2.5-inch hot-swappable SAS hard drives, SATA hard drives, or SATA SSD
Sixteen hard
drive/SSD plus eight
PCIe SSD systems
Up to sixteen 2.5-inch hot-swappable SATA hard drives or SATA SSD plus eight 2.5-inch PCIe SSD
Limitations for SATA SSDs backplane congurations:
• Four hard drive systems: No limitations
• x24 hard drive systems with unied backplane (single-PERC conguration): SATA SSDs might be installed in slots 12-23 only.
• x24 hard drive systems with Dual-PERC (performance) conguration: No limitations
• x16+8 PCIE systems: SATA SSDs might only be installed in slots 8-15.
NOTE
: SSD/SAS/SATA hard drives cannot be mixed in a system.
The hot-swappable hard drives connect to the system board through the hard drive backplane. Hot-swappable hard drives are supplied in
hot-swappable hard drive carriers that t in the hard drive slots.
