7. Remove the Media Card Reader.
8. If you are not installing another drive in the FlexBay and metal shields are present in your computer (see About the Metal Shields Present in Some Drive
Configurations), install the vented metal insert over the FlexBay and the empty space beneath it:
a. Holding the metal insert at an angle, insert its two upper screws into the slot that runs along the inside of the FlexBay.
b. Rotate the bottom of the vented metal insert down and insert its two bottom screws into the slot in the open area beneath the FlexBay.
c. Push the vented metal insert until it clicks into place and its metal tabs rest flush against the chassis surface.
Then, install a drive-panel insert (see Replacing a Drive-Panel Insert).
9. If you are installing another drive in the FlexBay, see the appropriate installation instructions in this section.
10. Replace the desktop retention insert and fold down its handle.
11. Reinstall the drive panel (see Replacing the Drive Panel).
12. Ensure that all connectors are properly cabled and firmly seated.
13. Replace the computer cover (see Replacing the Computer Cover).
14. Connect the computer and devices to electrical outlets, and turn them on.
