43
Operating the monitor
Table 28. OSD menu
Icon Menu and submenu Description
Brightness/Contrast Adjusts the brightness and the contrast of the display.
Brightness Brightness adjusts the luminance of the backlight.
Move the joystick up or down to increase or decrease the brightness level (min 0 ~ max
100).
Contrast Adjust Brightness first, and adjust Contrast only if you need further adjustment.
The Contrast function adjusts the degree of difference between darkness and lightness
on the monitor screen.
Move the joystick up or down to increase or decrease the contrast level (min 0 ~ max
100).
