The SFP+ transceiver modules are installed into the front-end ports of a storage controller. Fiber-optic

cables are connected from the SFP+ transceiver modules in a storage controller to SFP+ transceiver

modules in Fibre Channel switches.

Guidelines for Using SFP+ Transceiver Modules

The SCv2000/SCv2020 storage system supports the use of SFP+ transceiver modules for 16 Gb FC

connectivity.

Before installing SFP+ transceiver modules and fiber-optic cables, read the following guidelines.

CAUTION: When handling static-sensitive devices, take precautions to avoid damaging the

product from static electricity.

• Use only Dell supported SFP+ transceiver modules with the SCv2000/SCv2020. Other generic SFP+

transceiver modules are not supported and may not work with the SCv2000/SCv2020.

• The SFP+ transceiver module housing has an integral guide key that is designed to prevent you from

inserting the transceiver module incorrectly.

• Use minimal pressure when inserting an SFP+ transceiver module into an FC port. Forcing the SFP+

transceiver module into a port may damage the transceiver module or the port.

• The SFP+ transceiver module must be installed into a port before you connect the fiber-optic cable.

• The fiber-optic cable must be removed from the SFP+ transceiver module before you remove the

transceiver module from the port.

Install an SFP+ Transceiver Module

Complete the following steps to install an SFP+ transceiver module in a 16 Gb FC storage controller.

About this task

Read the following cautions and information before installing an SFP+ transceiver module.

WARNING: To reduce the risk of injury from laser radiation or damage to the equipment, observe

the following precautions:

• Do not open any panels, operate controls, make adjustments, or perform procedures to a laser

device other than those specified in this document.

• Do not stare into the laser beam.

CAUTION: Transceiver modules can be damaged by electrostatic discharge (ESD). To prevent ESD

damage to the transceiver module, take the following precautions:

• Wear an antistatic discharge strap while handling transceiver modules.

• Place transceiver modules in antistatic packing material when transporting or storing them.

Steps

1. Position the transceiver module so that the key is oriented correctly to the port in the storage

controller.

Connect the Front End
