Figure 75. Attach Label to Cable
2. Wrap the label around the cable until it fully encircles the cable. The bottom of each label is clear so
that it does not obscure the text.
Figure 76. Wrap Label Around Cable
3. Apply a matching label to the other end of the cable.
Adding a Single Expansion Enclosure to a Chain Currently
in Service
Use caution when adding an expansion enclosure to a live Storage Center system to preserve the
integrity of the existing data.
Prerequisites
Install the expansion enclosure in a rack, but do not connect the expansion enclosure to the storage
system
. For more information, see the Dell Storage Center SC100/SC120 Expansion Enclosure Getting
Started Guide.
About this task
To add an expansion enclosure to an existing chain, connect the expansion enclosure to the end of the
chain.
98
Adding or Removing an Expansion Enclosure
