(4-port I/O card only) Physical WWN of storage controller 2: port 3 ________________
Table 12. Virtual WWNs in Fault Domain 1
Virtual WWN of storage controller 1: port 1 ________________
Virtual WWN of storage controller 2: port 1 ________________
(4-port I/O card only) Virtual WWN of storage controller 1: port 3 ________________
(4-port I/O card only) Virtual WWN of storage controller 2: port 3 ________________
Table 13. Physical WWNs in Fault Domain 2
Physical WWN of storage controller 1: port 2 ________________
Physical WWN of storage controller 2: port 2 ________________
(4-port I/O card only) Physical WWN of storage controller 1: port 4 ________________
(4-port I/O card only) Physical WWN of storage controller 2: port 4 ________________
Table 14. Virtual WWNs in Fault Domain 2
Virtual WWN of storage controller 1: port 2 ________________
Virtual WWN of storage controller 2: port 2 ________________
(4-port I/O card only) Virtual WWN of storage controller 1: port 4 ________________
(4-port I/O card only) Virtual WWN of storage controller 2: port 4 ________________
Supported Operating Systems for Storage Center
Automated Setup
Setting up a Storage Center using the Discover and Configure Uninitialized SCv2000 Series Storage
Center wizard and the Host Setup wizards requires 64-bit versions of the following operating systems:
Red Hat Enterprise Linux 6 or later
SUSE Linux Enterprise 12 or later
Windows Server 2008 R2 or later
Install and Use the Dell Storage Client
You must start the Dell Storage Client as an Administrator to run the Discover and Configure Uninitialized
SCv2000 Series Storage Centers wizard.
1. Go to www.dell.com/support and download the Dell Enterprise Manager software.
2. Install the Enterprise Manager Client on the host server.
To discover and configure a Storage Center, the software must be installed on a host server that is on
the same subnet as the storage system.
3. To start the software on a Windows computer, double-click the Enterprise Manager Client shortcut.
To start the software on a Linux computer, execute ./Client from the var/lib/dell/bin
directory.
80
Discover and Configure the Storage Center
