Disassembly and reassembly
Topics:
• Stand
•
Cable cover
• Side Cover
• Speaker cover
• Hard drive
• Optical drive
• System board shield
• Memory modules
• Solid State Drive
• Coin-cell battery
• WLAN card
• Heat sink
• Speaker
• Display panel
• Chassis frame
• Power supply unit
• VESA mount bracket
• Converter board
• System fan
• Intrusion switch
• Power and On-Screen Display buttons board
• Processor
• System board
Stand
Removing the stand
NOTE:
The system is shipped with three different types of stands:
● Height Adjustable Stand
● Basic Stand
● Articulating Stand
The removal procedure is the same for all the three stands.
1. Follow the procedure in Before working inside your computer.
2. Place the computer on clean, flat surface with the display facing downward.
3. To remove the stand:
a. Press the tab on the cover to release the stand [1].
b. Lift the stand upward [2].
NOTE: Each of the three stands will attach and detach in the same manner.
2
10 Disassembly and reassembly
