Dell W14B - Memory Specifications; Video Specifications; Audio Specifications

Feature Specification
Total cache
Up to 8 MB cache depending on processor type
Chipset
Intel Q270 chipset
Memory specifications
Feature Specification
Memory type up to 2400 MHz, unbuffered non-ECC, dual‑channel DDR4 2133 configuration (2133 MHz on Intel 6th
generation processors)
Memory capacity 4 GB, 8 GB
Memory
connectors
two internally-accessible DDR4 SODIMM sockets
Minimum
memory
4 GB
Maximum
memory
16 GB
Video specifications
Feature
Specification
Video Controller
● Integrated Intel HD 630/610/530/510 Graphics
● Optional AMD Radeon M465, 2GB
Video Memory shared memory
External display
support
DisplayPort, HDMI in and HDMI out (Optional only on FHD model configuration 7450 AIO)
Audio specifications
Feature
Specification
Controller Intel High Definition Audio with Waves MaxxVoice Pro
Speaker single 4-ohms speakers in both the left and right speaker assembly (4 W average per channel)
Internal speaker
amplifier
up to 7.6 W at 4-ohm per channel
Internal
microphone
support
dual digital microphone
Volume controls Program menus, and keyboard media-control keys
WARNING: Excessive sound pressure from earphones or headphones can cause hearing
damage or loss. Adjustment of the volume control as well as the equalizer to settings
other than the center position may increase the earphones or headphones output voltage,
and therefore the sound pressure level. The use of factors influencing the earphones or
headphones output other than those specified by the manufacturer(e.g. operating system,
equalizer software, firmware, driver, etc.) may increase the earphones or headphones
output voltage and therefore the sound pressure level. The use of earphones or headphones
Technical specifications 73
