Installing the system board shield
1. Align and slide the system board shield until it snaps in.
2. Install the:
a. back cover
b. stand
3. Follow the procedure in After working inside your computer.
Memory modules
Removing the memory module
1. Follow the procedure in Before working inside your computer.
2. Remove the:
a. stand
b. back cover
c. system board shield
3. To remove the memory module:
a. Pry the retention clips away from the memory module until it pops up [1].
b. Lift the memory module from the connector [2].
20
Disassembly and reassembly
