Installing the coin cell battery
1. Insert the coin cell battery into the slot on the system board until it fits securely.
2. Install the:
a. system board shield
b. back cover
c. stand
3. Follow the procedure in After working inside your computer.
WLAN card
Removing the WLAN card
1. Follow the procedure in Before working inside your computer.
2. Remove the:
a. stand
b. back cover
c. system board shield
3. To remove the WLAN card:
a. Disconnect the antenna cables from the connectors on the WLAN card [1].
b. Remove the screw that secures the WLAN card to the system board [2].
c. Hold the WLAN card and pull it from the connector on the system board [3].
