Connector tabs
• Exercise care that the injector connector tab is not damaged during
installation. If the tab becomes damaged, the electrical connector may
disconnect in the future causing a customer complaint for engine
misfire.
Cushion Seal
Special procedures for cushion seal design injector:
• Verify seals at injector outlet and inlet as well as seal ring at inlet are
undamaged and properly located on the injector (see Figure 3-3)
• Use replacement seals as specified in parts listing for the application.
Do not substitute with any other seal ring.
• Fuel rail assembly must be installed with proper fasteners to proper
torque in order to maintain fuel seal.
TABLE 6.2
LUBRICANT NAME SUPPLIER VISCOSITY (cSt) @
40 deg C
RECOMMENDED / EVALUATED
FOR USE WITH...
Spindura 10 Equilon 10 Upper and lower injector seal rings
Spindura 22 Equilon 21 Upper and lower injector seal rings
DTE-24 Mobil 32 Upper and lower injector seal rings
DTE-25 Mobil 46 Upper and lower injector seal rings
DTE-26 Mobil 68 Upper and lower injector seal rings
Norpar 15 Exxon / Mobil <1 Upper and lower injector seal rings
Drawsol 60 DA Stewart 1 - 2 Upper and lower injector seal rings
NocoLube AW 46 NOCO Energy 46 Upper and lower injector seal rings
NocoLube AW 32 NOCO Energy 32 Upper and lower injector seal rings
Advantage Spindle Oil Advantage
Lubrication
Specialties
10 Upper and lower injector seal rings
Penreco Red
Petrolatum Grease
Penreco NA filler neck to tank installation; not
recommended for injector seal ring
lubrication
Table 6-2 - Recommended seal ring lubricants
6.6 Component Assembly Best Practices
Component Assembly Best Practice worksheets are included in the
appendix (section 10.4.) These worksheets should be completed during a
walk through of the current (or proposed) fuel system assembly to engine
and vehicle assembly processes. A thorough evaluation of the customer
processes at both the engine and vehicle assembly plants where the
injector is used should occur as early as possible in the program to provide
