Product Description Multec 3.5 Fuel Injector Application Manual
3-10 Delphi Energy and Chassis Systems
Revision: 11/05-1
Figure 3-7 - Multec 3.5 Magnetic Circuit
Figure 3-8 - Multec 3.5 Fuel Flow Path
Pole Piece
Valve
Armature
Body
Coil
Outer
Body
Tube
Magnetic
Flux
Path
Fuel Flow Path
